Form Cure L.

FHL-CU-120V-01

Formlabs | Form Cure L

Starting at

$4,500.00

Post-curing SLA 3D printed parts enhances their mechanical properties and ensures optimal dimensional accuracy.

Form Cure L combines two 500W heaters with high-powered UV lights, a reflective inner chamber, and a rotating turntable to deliver a uniform, high-intensity cure.

Designed for versatility, Form Cure L supports both large-format prints and high-throughput production of smaller parts, and is compatible with all Formlabs SLA 3D printers.

Request a Quote

  • Priority Delivery

    Typically ships within 1 week

  • Ease of Use

    Engineered for quick and simple cleanup

  • Warranty

    1-Year warranty

  • After-Sale Service

    Email and Phone support

  • Product Specifications
  • Product Services

Technical Specifications

Printer Compatibility

Form 4L, Form 4BL, Form 3L, Form 3BL, Form 4, Form 4B, Form 3/+, Form 3B/+, Form 2

Dimensions

69.0 x 54.0 x 44.5 cm
27.2 x 21.3 x 17.5 in

Weight

24 kg

53 lb

Turntable Diameter

39.5 cm
15.6 in

Maximum Part Height

32 cm
12.6 in

Maximum Cure Chamber

80 °C
176 °F

Light Source

45 multi-directional LEDs

LED Power

70 W

LED Radiant

36 W

LED Wavelength

375 nm, 405 nm

Power Requirements

Input (NA) 100 - 120 V
VAC, 50-60 Hz, 15 A
Input (EU) 220 - 240 V
VAC, 50-60 Hz, 8 A

Professional Support

Additional Warranty Available

Starting at $499

Expert Support

Phone support by our team. Available Monday through Friday, 9 am - 5 pm CST.

A CLOSER LOOK

EXPLORE THE FORM CURE L

Faster ramp up to optimal curing temperature

Dual heaters quickly heat parts to 80 °C in under 10 minutes, reducing post-processing time.

Support for large prints or high throughput

Large chamber, turntable, presets, and high power enable curing of big parts or batch jobs.

Uniform, high-intensity curing

Uses dual heaters, UV light, a reflective chamber, and a turntable for even curing on all parts.

Optimized for material properties

Completes polymer crosslinking, giving parts full strength, accuracy, and heat resistance.

FOR FORMLABS Form Cure L

OUR RELATED PRODUCTS

FIND YOUR ANSWERS HERE

FREQUENTLY ASKED QUESTIONS

Do parts need to be dry before curing with the Form Cure L?

Yes — wash and fully dry parts first. Residual solvent trapped inside can prevent proper curing or cause defects.

How do I choose the right time and temperature settings for the Form Cure L?

Use the pre-programmed resin profiles on the touchscreen. For unusual geometries (very thick, thin, or dense parts), you might need to adjust settings upward.

What is the maximum size of a part I can cure using the Form Cure L?

The curing chamber supports parts up to about 39.5 cm diameter and 32 cm height on the turntable.

How often should I clean and maintain internal surfaces for the Form Cure L?

Regularly. Clean the chamber, light diffusers, door, and turntable every 1-3 months (depending on how heavily used), especially if there’s debris or cured resin accumulating.

What safety / environmental setup is needed for operation of the Form Cure L?

  • Put the Cure L in a dry, indoor space. Keep clearances so no walls or combustible materials are too close.
  • Ensure proper electrical supply (NA vs EU voltage).
  • Use gloves/eye protection as surfaces and parts can get hot during curing.
