PioCreat | G5Ultra 3D Printer

PioCreat | G5Ultra 3D Printer

Starting at

$4,950.00

The G5Ultra Pellet 3D Printer uses cost-effective thermoplastic pellets for high-speed, efficient production. It features a nozzle temperature up to 420 °C, a heated bed that reaches 120 °C, and a screw extruder capable of processing a wide range of materials. Engineered for versatility, it’s ideal for education, research, design studios, prototyping, and other professional applications.

Request a Quote

  • Priority Delivery

    Typically ships within 1 week

  • Ease of Use

    Engineered for quick and simple setup

  • Warranty

    1-Year warranty

  • After-Sale Service

    Email and Phone support

  • Product Specifications

  • Request Information

Technical Specifications

Technology / Process

FGF (Fused Granulate Fabrication) — prints directly from thermoplastic pellets/granules rather than filament.

Build (Print) Volume

500 × 500 × 400 mm (X × Y × Z)

Machine / Envelope Size

Approx. 765 × 890 × 1,040 mm (Width × Depth × Height)

Nozzle / Extruder Temperature

Up to approximately 420 °C (for the extruder / nozzle)

Print Bed / Heated Platform Max Temp

Up to about 120 °C for the heated bed / build surface.

Nozzle Diameter Range

Standard nozzles ~0.8 mm (or 1.0/2.0 mm); broader range 0.4 mm to 3.0 mm supported in some specs.

Pellet / Granule Feedstock Size

Supports pellets/granules sized approx. 2 mm to 5 mm diameter.

Hopper / Pellet Container Capacity

~3 litres (~3,000 ml) hopper capacity.

Printing Speed / Flow Rate

Up to ~220 mm/s printing speed; material flow up to ~0.8 kg/hour.

Layer Thickness (Resolution)

Thickness range approx. 0.2 mm up to ~1.0 mm.

Material Compatibility

Wide variety: standard and engineering thermoplastics and composites (e.g., PLA, ABS, PA-GF, PA-CF, PC-CF, PETG-GF, PP-GF, recycled pellets, etc.).

Power Requirements / Voltage

AC 100-240 V 50/60 Hz (some listings state ~1450 W rated power)

File / Connectivity / Software

Accepts STL / OBJ / AMF formats; works with PioCreat Slicer; also compatible with Cura/Simplify3D; supports USB / WiFi for file transfer/monitoring.

Need more information?

We’re committed to providing expert insights and responsive service to guide you every step of the way. To get started, simply fill out the form below and we’ll be in touch shortly.

Need more information?

We’re committed to providing expert insights and responsive service to guide you every step of the way. To get started, simply fill out the form below and we’ll be in touch shortly.

Accurate 3D Printing

Why Choose the G5Ultra?

Faster Turnaround

Achieve printing speeds up to ten times faster than traditional filament systems, accelerating your production timeline.

Sustainable Manufacturing

Utilize pellets and recycled plastics to create eco-conscious parts and minimize waste in additive production.

Superior Material Performance

Print directly with virgin or engineering-grade materials to maintain their full mechanical and thermal properties.

Lower Production Costs

Pellet-based 3D printing dramatically reduces material expenses—up to ten times cheaper than filament printing.

MEET THE PRODUCT

Watch the G5Ultra in Action

FIND YOUR ANSWERS HERE

FREQUENTLY ASKED QUESTIONS

What materials can the G5Ultra print?

It supports a wide range of pellets, including PLA, ABS, PETG, nylon, PP, and carbon- or glass-fiber composites.

How fast can the G5Ultra print?

The G5Ultra reaches speeds up to 220 mm/s with a material flow of about 0.8 kg per hour.

What is the build volume of the G5Ultra?

It offers a large 500 × 500 × 400 mm print area for industrial and prototyping applications.

What are the temperature capabilities of the G5Ultra?

The nozzle heats up to 420 °C, and the bed reaches 120 °C — ideal for engineering-grade polymers.
